CHINT NH2-100 Isolator

NH2-100 Isolator

Product Description

Click to view Product Catalogue

1. General
Isolation
Designed match DZ series MCBs/RCBOs
2. Technical features
Manufactured according to IEC/EN 60947-3
Electric ratings: 32A, 63A,100A, 125A, 230/400V~240/415V, 50/60Hz
Rated short circuit breaking capacity: 20le, t=0.1s
Electric life: 1500
Mechanical life: 8500
Connection: From top and bottom

request a quote
back to products

Product variation & more info

Product Code Description Poles Amps
NH2-100-1P-032A Isolator 1 32
NH2-100-1P-063A Isolator 1 63
NH2-100-1P-100A Isolator 1 100
NH2-100-2P-032A Isolator 2 32
NH2-100-2P-063A Isolator 2 63
NH2-100-2P-100A Isolator 2 100
NH2-100-3P-032A Isolator 3 32
NH2-100-3P-063A Isolator 3 63
NH2-100-3P-100A Isolator 3 100
NH2-100-4P-032A Isolator 4 32
NH2-100-4P-063A Isolator 4 63
NH2-100-1P-100A Isolator 4 100
