ND9 Indicator Light

ND9 Indicator Light

1. General

 1.1 Electric ratings: 230V, AC50/60Hz;

1.2 Rated insulation voltage Ui: 500V;

1.3 Protection grade: IP20

1.4 Rated operational current: ≤20mA

1.5 Life: LED≥30000h;

1.6 Standard: IEC/EN 60947-5-1

2. Operating Conditions

2.1 Ambient temperature: -5℃~+40℃, average temperature in 24 hours not exceed +35℃;

2.2 Altitude: ≤ 2000m;

2.3 Air conditions: At mounting site, relative humidity not exceed 50% at the max temperature of +40℃, higher relative humidity is allowable under lower temperature. For example, RH could be 90% at +20℃. Special measures should be taken to occurrence of dews;

2.4 Mounting category: Ⅱ, Ⅲ;

2.5 Pollution grade: Ⅱ;

2.6 Mounting mode: TH35-7.5 standard rail, inclination between mounting and vertical plane not exceed 5°

3. Wiring

2 Cross section area of the conductor is 1.0mm , and tightening torque should be 0.8N•m
